LILYGO TTGO T-Beam (tracker)

This is LILYGO TTGO T-Beam ver. 1.1 module with ESP32, LoRa 433 MHz or 868 MHz RF module, WiFi, Bluetooth, GPS, 18650 battery holder and I2C OLED display.

Read moreShow less
60.50 € (tax incl.)
60.50 €
50.00 € without tax
version
  • 433 MHz
  • 868/915 MHz
in stock, shipped in 2-3 days

Price history     Price history
Add to compare0
Love
Add to wishlist
Description

LoRa IoT module with OLED display, 18650 battery holder and ESP32, LoRa 433 MHz or 868 MHz module, integrated GPS, WiFi, Bluetooth and AXP192 charger chip. Simply LoRa APRS gateway with simply 70 cm antenna is able to do 100 km+ of coverage range. ODX for OK2ZAW-17 (https://aprs.fi/info/?call=OK2ZAW-17) is over 700 km.


Using


Main functions

  • RF frequency 433 MHz or 868/915 MHz
  • GPS module for tracker applications
  • ESP32 core
  • 2.4 GHz WiFi and Bluetooth with Integrated antenna
  • 8 MB PSRAM and 4 MB Flash memory
  • Up to 20 dBm of RF power
  • Modulations: FSK, GFSK, MSK, GMSK, LoRa™️, OOK
  • OLED 0.96 inch 128x64 (included)

Parameters

  • ESP32 core
  • 8 MB PSRAM, 4 MB Flash memory
  • WiFi and Bluetooth
  • LoRa module 433 MHz (433/470 MHz) or 868/915 MHz
  • Working voltage 1.8 to 3.7 V
  • Current 10 to 120 mA
  • TX power up to 20 dBm
  • RX sensitivity -139 dBm (146 bps)
  • Modulations: FSK, GFSK, MSK, GMSK, LoRa™️, OOK
  • Operating temperature: -40 ℃ to +85 ℃
  • GPS: NEO-6M with backup battery
  • USB 5 V/charging current max. 0.5 A
  • Charger chip AXP192
  • OLED display 0.96 inch 128x64
  • SMA connector for LoRa antenna
  • Small LoRa antenna included


Included in package

T-Beam board
OLED display
PIN headers
GPS patch antenna
Small LoRa antenna


Examples, 3D models, schematic

If you want to know more please check LoRa github.

lilygo ttgo 433 MHz 868 MHz tracker qro.cz hamparts.shop



lilygo ttgo 433 MHz 868 MHz tracker qro.cz hamparts.shop



Read moreShow less
Product Details

Data sheet

design
pcb module
dimensions
28.5x27x5 mm
100x33 mm
weight (brutto)
0.08 kg

Specific References

ean13
1000090110060
