LILYGO TTGO LoRa32 (gateway)

This is LILYGO TTGO LORA32 ver. 1.6 module with ESP32, LoRa 433 MHz or 868 MHz RF module, WiFi, Bluetooth and I2C OLED display.

Read moreShow less
38.72 € (tax incl.)
38.72 €
32.00 € (without tax)
version
  • 433 MHz
  • 868/915 MHz
in stock, shipped in 2-3 days

Price history     Price history

The lowest price in the 30 last days was 38.72 €

Add to compare0
Love
Add to wishlist
Description

LoRa IoT module with OLED display, ESP32, LoRa 433 MHz or 868 MHz module, integrated WiFi and Bluetooth. Simply LoRa APRS gateway with simply 70 cm antenna is able to do 100 km+ of coverage range. ODX for OK2ZAW-17 (https://aprs.fi/info/?call=OK2ZAW-17) is over 700 km.


Using


Main functions

  • RF frequency 433 MHz or 868/915 MHz
  • ESP32 PICO-D4 core
  • 2.4 GHz WiFi and Bluetooth with Integrated antenna
  • 8 MB PSRAM and 4 MB Flash memory
  • USB to UART CP2104
  • Up to 20 dBm of RF power
  • Modulations: FSK, GFSK, MSK, GMSK, LoRa™️, OOK
  • OLED 0.96 inch 128x64 (included)

Parameters

  • ESP32 PICO-D4 core
  • 8 MB PSRAM, 4 MB Flash memory
  • USB to UART CP2104
  • WiFi and Bluetooth
  • LoRa module 433 MHz (433/470 MHz) or 868/915 MHz
  • Working voltage 1.8 to 3.7 V
  • Current 10 to 120 mA
  • TX power up to 20 dBm
  • RX sensitivity -139 dBm (146 bps)
  • Modulations: FSK, GFSK, MSK, GMSK, LoRa™️, OOK
  • Operating temperature: -40 ℃ to +85 ℃
  • OLED display 0.96 inch 128x64
  • SMA connector for LoRa antenna
  • Small LoRa antenna included
  • Power chip TP4054


Included in package

TTGO LoRa32 v1.6
OLED display
PIN headers
Small LoRa antenna
Battery connector with wires


Examples, 3D models, schematic

If you want to know more please check LoRa github.

lora32 lilygo ttgo 433 MHz 868 MHz qro.cz hamparts.shop



lilygo ttgo Lora32 433 MHz 868 MHz qro.cz hamparts.shop



Read moreShow less
Product Details

Data sheet

design
pcb module
PCB dimensions
27x65 mm
product weight (brutto)
0.03 kg
package dimensions
12x10.5x4.5 cm

Specific References

ean13
1000090110046
