MALACHITE V5 SDR RX

SDR receiver 10kHz to 250 MHz, 400 MHz to 2GHz with waterfall and spectrum analyzer

Read moreShow less
240.79 € (tax incl.)
240.79 €
199.00 € (without tax)
in stock, shipped in 2-3 days

Price history     Price history

The lowest price in the 30 last days was 240.79 €

Add to compare0
Love
Add to wishlist
Description

This is Malachite DSP SDR Receiver, new version 2023 - V5. It is a standalone SDR receiver in a metal enclosure with a 3.5" 480x320 LCD. The receiver has a frequency range of 10 kHz to 2 GHz with an exception between 250 MHz and 400 MHz. It supports all AM, SSB, DSB, CW, NFM and WFM modulations. Stereo RDS is supported for WFM with informations at LCD display. You can also view the signal spectrum on the LCD in 160kHz, 80kHz or 40kHz bandwidths. Thanks to the built-in 3.7V 5000mAh battery, you can listen for up to 12 hours.

The USB port allows connection to a PC with CAT support, IQ data output and audio. You can use popular SDR softwares and transfet CAT and IQ data from SDR receiver to PC. There you can use more SDR SW features!

The antenna is connected via a 50 Ohm SMA connector, with the option to connect a high impedance antenna - automatic switching inside. There is also a built-in preamplifier and an adjustable attenuator from 0 to 30 dB. RF filter switching is automatic.


Usage

  • SDR receiver with many modes
  • Searching for QRM source
  • Hobby SDR with spectrum analyzer
  • IQ data over USB
  • CAT and IQ for popular SDR SW

Parameters

  • Frequency range: 10 kHz ~ 250 MHz, 400 MHz ~ 2 GHz
  • Modulation type: AM, SSB, SDB, CW, NFM, WFM (stereo RDS)
  • Spectrum width: 160 kHz, 80 kHz, 40 kHz
  • LCD 3.5 inch 480x320
  • Touch display
  • Spectrum analyzer and waterfall
  • USB support CAT, IQ and audio
  • CAT as TS-480
  • IQ data for HDSDR, SDR# etc.
  • Dynamic range: 82 dB
  • Antenna SMA, 50 Ohm or Hi-Z
  • Automatic RF filter switching
  • Built-in preamp
  • Variable ATT 0 to 30 dB
  • DSP: AGC, ANF, NR, NB
  • Tuner: MSi001
  • CPU: STM32H743 ARM at 480 MHz
  • Built-in 3.7V 5000 mAh
  • Metal enclosure
  • Input SMA female connector
  • Mini USB 2.0 (1m long)
  • Telescopic antenna (65 cm)
  • Hardcase
  • Dimensions: 16.3 x 8.5 x 2.9 cm

Software compatible

CAT and IQ support at USB
HDSDR
SDR#
And many others


Included in package

Malachite V5
USB cable (length 1m)
Telescopic antenna (length 65 cm)
Hardcase
Fabric cover


Technical articles

Please check our technical article about MALACHITE SDR.

Protect the receiver input from strong signals and ESD when you use it with bigger antennas! For HF range we recommend our RF limiters. For VHF/UHF our Surge protectors or coaxial shorts.

malachite sdr receiver schematic qro.cz hamparts.shop



malachite sdr receiver qro.cz hamparts.shop



malachite sdr receiver qro.cz hamparts.shop



Example of USB IQ data with SDR#

sdr receiver malachite example of usb iq data with sdr qro.cz hamparts.shop

Read moreShow less
Product Details

Data sheet

product weight (brutto)
0.5 kg
package dimensions
12x10.5x4.5 cm
