High power termination resistor 100 Ohm 30W
Flanged mounted termination resistor
14.52 €
(tax incl.)
14.52 €
12.00 € (without tax)
12.00 € (without tax)
Add to compare0
Love
Add to wishlist
This is flange mount high power resistor for variable use. These resistors are mainly used in power splitters and combiners - the middle resistor in Wilkinson. Resistance is between the strips, isolated from cooler.
Parameters
- Frequency: DC to 1.5 GHz
- Power rating: 30 W (see graph)
- Resistance range: 100 Ohm
- Resistor tolerance: 5%
- Substrate material: beryllium oxide ceramic
- Typical capacitance: ≤ 3 pF
- Operating temperature: -55 ℃ to + 150 ℃
- Temperature coefficient: ≤ 150 ppm/℃
- Manufacturer: RFTYT Technology Co., Ltd.
- Product name: RFTXXN-30RM1306
Info & Details
Datasheet: see our Attachments section
Dimensions (in mm)
graph temperature x power
mounting
Data sheet
- frequency range
- DC to 1.5 GHz
- product weight (brutto)
- 0.03 kg
- package dimensions
- 12x10.5x4.5 cm
