DC-DC step-down LM2596 3A with V-meter
Adjustable step-down voltage regulator with voltmeter
8.47 €
(tax incl.)
8.47 €
7.00 € (without tax)
7.00 € (without tax)
Add to compare0
Love
Add to wishlist
This is simply 3A step-down voltage regulator module based on LM2596. Including LED display voltmeter. You can select input or output voltage by the buttons. Excellent line and load regulation specifications. 150-kHz fixed-frequency internal oscillator. High efficiency and thermal shutdown and current-limit protection.
Application
- High efficiency voltage regulator
- 3A voltage regulator
- Simply power supply
Parameters
- Based on LM2596
- Current max.: 3A
- Input: 4 to 35V DC
- Output: 1.2 to 30V DC
- Input reverse polarity protection
- Thermal and current protection
- LED indication
- Display voltmeter
- Minimal resolution 0.1V
- Multi turn trimmer for V-set
- Size: 61x34x12 mm
Voltmeter calibration
Step 1. Press the right button so that the "OUT" LED is lit, the voltmeter shows the output voltage value; press and hold the right button for more than 2 seconds, release the button, the voltmeter and the "OUT" LED will flash synchronously so that you enter the output voltage calibration mode.
Step 2. Press the right button to add. Press the left button to subtract. As the step is less than 0.1V, the minimum voltage reading will be 0.1V, so you will need to press 1-5 times continuously to make the voltmeter change to 0.1V.
Step 3. TPress and release the right button for more than 2 seconds to exit the output voltage calibration mode. All set parameters are automatically turned off and saved.
Input voltage calibration steps
Step 1. Press the right button so that the "IN" LED lights up, the voltmeter displays the input voltage value; press the right button for more than 2 seconds and release it, the voltmeter and the "IN" LED flash synchronously so that you enter the input voltage calibration mode.
Step 2. and 3. correspond to the output voltage calibration method.
