4-way RCA double switch board

Two 4-way relay switches

Read moreShow less
22.99 € (tax incl.)
22.99 €
19.00 € (without tax)
in stock, shipped in 2-3 days

Price history     Price history

The lowest price in the 30 last days was 22.99 €

Add to compare0
Add to wishlist

This is a simple board with eight RCA connectors and a common screw terminal connector. These are two classic 1 to 4 switches. Switching by small relays.

This board can be used, for example, for switching Audio or PTT and ALC signals. The blue screw terminal connector is the common input/output of the middle of the switch for the upper and lower quad RCA connectors.

The board requires a power supply voltage of 8 to 20V AC or DC - 10 to 12V DC is recommended.

Switching is via positive voltage on pins 1 to 4. It is also possible to switch multiple ports at the same time! A simple rotary switch is sufficient for switching. A connecting flat cable (about 50 cm) between the board and the eventual switch is also included.



  • Two 1-to-4 switches
  • Audio switch - stereo
  • PTT and ALC from 1 to 4 devices
  • DC switching


  • Double 1-to-4 switch
  • More ports at the same time X-to-4
  • Supply voltage 8 to 20V AC to DC
  • Recommended 10 to 12V DC
  • Common ports - screw terminal
  • 4 + 4 ports at RCA female
  • Switching max. 2A 30V DC
  • Switching by positive voltage
  • LED indication
  • Size: 85x55x30mm
